Test 014: "LAT Diagnostic and Calibration Modes"

This test shall verify that the SIU FSW properly transitions to Diagnostic and Calibration Modes upon command, then properly executes the requested diagnostic and calibration algorithms.

Context (help)

Related Requirement(s) (help)

Section	Description		Other Tests
5.3	Functional Requirements
5.3.12	Charge Injection Calibration
5.3.12.1	TKR TOT
5.3.12.1.1	TOT Measurements
5.3.12.1.2	TOT Parameters Stored in File		002a
5.3.12.1.3	TOT TACK delay
5.3.12.2	TKR Threshold Scan
5.3.12.2.1	Threshold Scan Measurements
5.3.12.2.2	Threshold Scan Parameters Stored in File		002a
5.3.12.2.3	Threshold Scan TACK Delay
5.3.12.3	TKR Trigger Check
5.3.12.4	ACD Charge Injection Calibration Mode
5.3.12.4.1	Configure ACD Charge Injection Calibration Mode
5.3.12.4.2	ACD Charge Injection
5.3.12.4.3	ACD Charge Injection Calibration Mode Data
5.3.12.5	CAL Charge Injection Calibration Mode
5.3.12.5.1	Configure CAL Charge Injection Calibration Mode
5.3.12.5.2	CAL Charge Injection
5.3.12.5.2.1	CAL Charge Injection Triggers
5.3.12.5.2.2	CAL Charge Injection Charge
5.3.12.5.3	CAL Charge Injection Calibration Mode Data
5.3.12.5.3.1	CAL Charge Injection Histogram
5.3.12.5.3.2	CAL Charge Injection Calibration Mode Data Telemetry
5.3.12.5.3.3	CAL Charge Injection Calibration Mode Data Histograms
5.3.12.5.3.4	CAL Charge Injection Calibration Mode Data Event Data Option
5.3.13	Diagnostics
5.3.13.1	Diagnostics During Normal Operations
5.3.13.1.1	ACD Cosmic Ray Sample Events
5.3.13.1.2	CAL Log-Accept Occupancy
5.3.13.1.2.1	CAL Log-Accept Occupancy Histogram
5.3.13.1.2.2	CAL Log-Accept Occupancy Histogram Content
5.3.13.1.2.3	CAL Log-Accept Occupancy Transmission
5.3.13.1.3	CAL Range Occupancy
5.3.13.1.3.1	CAL Range Occupancy Histograms
5.3.13.1.3.2	CAL Range Occupancy Histogram Content
5.3.13.1.3.3	CAL Range Occupancy Histogram Transmission
5.3.13.1.4	CAL Log-Accept Occupancy Rates
5.3.13.1.4.1	CAL Log-Accept Occupancy Rates Accumulation
5.3.13.1.4.2	CAL Log-Accept Occupancy Rates Content
5.3.13.1.4.3	CAL Log-Accept Occupancy Rates Transmission
5.3.13.1.5	CAL Trigger Request Rates
5.3.13.1.5.1	CAL Trigger Request Rates Accumulation
5.3.13.1.5.2	CAL Trigger Request Rates Content
5.3.13.1.5.3	CAL Trigger Request Rates Transmission
5.3.13.1.6	CAL Log-Accept Occupancy Data, Detailed
5.3.13.1.6.1	CAL Log-Accept Occupancy Data, Detailed Accumulation
5.3.13.1.6.2	CAL Log-Accept Occupancy Data, Detailed Histogram
5.3.13.1.6.3	CAL Log-Accept Occupancy Data, Detailed Transmission
5.3.13.1.7	CAL Trigger Rates, Detailed
5.3.13.1.7.1	CAL Trigger Rates, Detailed Accumulation
5.3.13.1.7.2	CAL Trigger Rates, Detailed Content
5.3.13.1.7.3	CAL Trigger Rates, Detailed Transmission
5.3.13.1.8	CAL Range Occupancy Data
5.3.13.1.8.1	CAL Range Occupancy Data Accumulation
5.3.13.1.8.2	CAL Range Occupancy Data Content
5.3.13.1.8.3	CAL Range Occupancy Data Transmission
5.3.13.1.9	CAL Cosmic Ray (CR) Calibration
5.3.13.1.9.1	CAL CR Calibration Enable
5.3.13.1.9.2	CAL CR Calibration Disable
5.3.13.1.9.3	CAL CR Calibration Prescale Triggers
5.3.13.1.9.4	CAL CR Calibration Trigger
5.3.13.1.9.5	CAL CR Calibration Trigger - Additional
5.3.13.1.9.6	CR Calibration Data
5.3.13.1.9.7	CR Data Selection
5.3.13.1.10	TKR Cosmic Ray Calibration
5.3.13.2	Diagnostics during Special Modes
5.3.13.2.1	ACD Trigger Mode
5.3.13.2.2	ACD Pedestal Data
5.3.13.2.3	CAL Pedestal Value Data
5.3.13.2.4	CAL Pedestal Histogram Data
5.3.13.2.5	TKR GTRC Rates
