LAT-TKR Monitor Report

runID: 615035707
intput file: /scratch/29122/r0615035707_v000_tkrAnalysis.root
reference files:
/afs/slac.stanford.edu/g/glast/ground/releases/monitor/TKR/TkrMonitor/refRoot/calibOps-ref.root
/afs/slac.stanford.edu/g/glast/ground/releases/monitor/TKR/TkrMonitor/refRoot/muon-vertical-ref.root
Start Time: 2020/06/28, 11:15:10
Duration: 5644 seconds
Script version: 1.22
Script tag: calibTkrUtil-03-00-00

Tower averaged trigger efficiency	Lat averaged trigger efficiency: 99.6%
Layer displacement from reference [micron]	NOTE layer displacement, | 35.6/6.3 | > 5.0: Tower 0 Layer Y2 layer displacement, | -33.7/6.2 | > 5.0: Tower 4 Layer X0 layer displacement, | 27.3/5.2 | > 5.0: Tower 4 Layer X3 layer displacement, | 28.2/5.5 | > 5.0: Tower 4 Layer X5 layer displacement, | -21.9/3.9 | > 5.0: Tower 6 Layer Y10 layer displacement, | -20.5/3.9 | > 5.0: Tower 6 Layer Y12
Number of Dead GTFE	ERR Dead GTFE(No.20): Tower 0 Layer X1 Dead GTFE(No.21): Tower 0 Layer X1 Dead GTFE(No.3): Tower 0 Layer Y3
Layer averaged Strip Occupancy	WARN trig-mask required: strip [1419]: Tower 10 Layer Y16 trig-mask required: strip [1355]: Tower 12 Layer Y15 data-mask required: strip [1419]: Tower 10 Layer Y16 data-mask required: strip [1355]: Tower 12 Layer Y15
Tower averaged hit efficiency	Lat averaged hit efficiency: 99.8%
Fraction of no-hit strips	Lat averaged fraction of no-hit strips: 0.0%
Layer-OR occupancy
Fraction of Saturated Events
Layer averaged hit inefficinecy	NOTE layer efficiency, 85.5% < 90.0%: Tower 0 Layer X1 layer efficiency, 84.6% < 90.0%: Tower 0 Layer Y3 layer efficiency, 89.4% < 90.0%: Tower 0 Layer Y4 layer efficiency, 80.6% < 90.0%: Tower 3 Layer Y17
Layer averaged TOT peak distribution
